Seed cleaner machine vibration grader is to separate wheat, bean, corn, seed into different sizes. Grains can be classified into big, medium and small size with different layers of sieves.
The vibration sieve can separate big and small impurities from all kinds of grain and seeds.
The material can be classified into big, medium and small particles with different layers of sieves.
It is widely used in seed processing and agricultural product processing industry.
Durable, Stable and Easy to handle.
| Vibration Grader | Model | Layer |
Sieve Surface Area (mm) |
Power kW |
Capacity t/h |
Weight Kg |
Overall Size L×W×H mm |
| 5XFJ-7.5B | Three | 1250x2400 | 1.5 | 7.5 | 1040 | 3520x2130x1860 | |
| 5XFJ-7.5C | Four | 1250x2400 | 1.5 | 7.5 | 1080 | 3520x2130x1860 | |
| 5XFJ-10B | Three | 1500x2400 | 1.5 | 10 | 1160 | 3530x2440x1840 | |
| 5XFJ-10C | Four | 1500x2400 | 1.5 | 10 | 1210 | 3530x2440x1840 | |
| 5XFJ-10D | Five | 1500x2400 | 1.5 | 10 | 1360 | 3530x2450x2120 | |
| 5XFJ-20Y | Double screen box | 1500x2400 | 1.5 | 15-20 | 1320 | 3560x2310x1880 | |
| 5XFJ-7.5BC | Three | 1250x3600 | 1.5 | 7.5 | 1200 | 4720x2130x1900 | |
| 5XFJ-7.5CC | Four | 1250x3600 | 1.5 | 7.5 | 1360 | 4720x2130x1900 | |
| 5XFJ-20C | Eight | 1500x2400 | 3 | 15-20 | 2800 | 4130x2400x4390 | |
| 5XFJ-30C | Twelve | 1500x2400 | 4.5 | 22.5-30 | 4200 | 4130x2400x5530 |
