5XFZ-25S Air Screen Cleaner With Gravity Table & 5XFJ-10C Vibration Grader

It always used for the soybean, peanut, sesame cleaning, and capacity can reach to 7-8t/h. purity can be more than 99%

Product Details

Function

It is to remove dust, leaf, light impurity by the air screen. And remove above 90% bad seed, like blighted seed, budding seed, damaged seed (by insect), rotten seed, deteriorated seed, moldy seed, non-viable seed, seed with black powder sick by the gravity table. Remove the big impurity from the back half screen.

Selling Point

It always used for the soybean, peanut, sesame cleaning, and capacity can reach to 7-8t/h. purity can be more than 99%

Specification

Model:

5XFZ-25S Air Screen Cleaner With Gravity Table

 & 5XFJ-10C Vibration Grader

Power(kw):14
Weight(kg):3360
Voltage:

380V, 50HZ, Three Phases

Sieve Size:Gravity Table:1700mmx1600mm
   Front Sieve:1250mmx1200mm
Capacity(t/h):6-8t/h Based On Soybean
Overall Size L×W×H(mm):6200x2300x3600
